Rubber adapter mats
for slot vacuum chucks
Nr. A B C
00416 200 300 3 226
00609 200 500 3 378
00564 200 600 3 453
00009 300 150 3 170
00010 350 150 3 200
00011 400 200 3 300
00013 350 250 3 330
00014 300 300 3 340
00015 250 400 3 370
00016 400 300 3 460
00017 400 400 3 602
00415 500 300 3 560
00164 500 500 3 941
00418 500 1000 3 1890
00437 600 300 3 678
00414 600 400 3 904
00409 1000 1000 3 3766
00682 1000 2000 3 7550
00732 1000 2000 1 2500
00733 1000 2000 1,5 3980
46
Rubber adapter mats, brown, for use on slot type vacuum
chucks (see also page 40)
i
Nr. l x w Thickness
14927 2000 x 400 1 1
17302 9100 x 400 1 4,5
Preference item:
Articles with green diamond
are available ex stock!
Blue mat (meterwise from roll): Most accurate product, highest friction, ideal for parts with small
clamping areas, reusable
Black mat (cut to order): Can be milled over, low friction, reusable
Red mat (cut to order): Cannot be milled over, medium friction, ideal for drilling holes through
parts, reusable
Slot vacuum chucks
Rubber adapter mats
blue
The blue rubber adapter mat is placed between part and
chuck. It covers areas of the chuck not in use and secures
part against slipping due to high friction value.
Areas covered by part, must be punched with holes or cut
with slits.
Rubber adapter mat - blue.
Only available as a complete roll.
Other dimensions available on request
