73
i
Vacuum Switch
with LED Display
Vacuum switch, electronic, with adjustable safety values.
Used as safety switch for dry working environments.
i
Accessories
Nr. Maße (mm) U
282703 55x30x32 24V 11
Nr. Maße (mm) U
283126 h=92, ø33 24V 50
Supply includes:
Connecting cable 5m, angled
Operation manual
Technical data:
Measuring range: -1 to + 10 bar
Connection: G1/8“
Operating current (V): 18-32 DC
Electricity load (mA): 100
Compression resistance (bar): 20
Readiness delay time (s): 0,3
Min. reaction time switch off (ms): 2,5
Adjustable delay time sD, dr (s): 0; 0,002...5
Protection: IP 65
Weight (kg): 0,106
Display: Display unit 4 x LED green
Switching status 2 x LED yellow
Supply includes:
Connecting cable 5m, angled
Operation manual
Vacuum switch, electronic, with comprehensive
adjusting/programming possibilities.
Used as safety switch for wet and explosion
protected working environments.
Technical data:
Vacuum display, controlled electronically
Upper and lower vacuum safety values
(hysteresis) freely adjustable
Connection: G1/4“
Adjustable reaction time
Programming of switching outputs
Hno = Hysteresis /Closer
Hnc = Hysteresis /Opener
Fno = Hysteresis /Closer
Fno = Hysteresis /Opener
(Close contact/break contact)
Maximum overload pressure 10bar
Vacuum Switch
with LED Display
Preference item:
Articles with green diamond
are available ex stock!
