Alu Structure Plates
rotating
Robot measuring cell for optical measuring
Configuration:
- 2 vertical structure plates mounted on rotating hovercraft supports,
rotable by 180°
- 1 stationary , horizontal structure plate with extended height
- On hovercraft, rotary and tact tables
- To reach both work pieces or do assembly from outside without interrupting
measuring process
- Integrated safety monitoring, release switch
Horizontal structure plate on motorized
rotary table (shown without base
unit). Force is directed to the rotary
plate via inner plate structure
Vertical alu structure plate on hovercraft rotary table
