Roller slide
adjustment using a screw spindle
Nr. A (AF) B max. load shift
82453 16 M4 20 kg ± 9 89
82172 25 M6 50 kg ± 13,5 242
82173 40 M10 150 kg ± 22 970
82398 50 M12 250 kg ± 27 1.910
c·e
ALUFIX ADJUSTING ELEMENTS
Other dimensions on request
Cross roller slide
adjustment using a screw spindle
Nr. A (AF) B max. load shift
82461 16 M4 20 kg ± 9 178
82462 25 M6 50 kg ± 13,5 484
82463 40 M10 150 kg ± 22 1.940
82399 50 M12 250 kg ± 27 3.820
Preference item:
Articles with green diamond –>
are available ex stock!
–> Article colour anodized natural
-> Classic and/or ECO
–> Article colour anodized black
